TOYODA/WELE CNC BRIDGE MILL

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


SB316YM
18398
Milling Machines
Bridge Mill, CNC
new
68000 (LB)
2019
$0.00

Feature Video

Description

SOLD                       SOLD                               SOLD

Toyoda, Wele, Five Face, Head Changer, Vertical/Horizontal, Bridgecenter, Double Column, Vertical Machining Center. Fanuc 31i-MB control, Right angle head Changer, 60 Tool Capicty Auto Tool Changer Vertical And Horizontal, Coolant through Spindle, Full splash guard, 2 speed Geared head 6,000 RPM, Big plus Spindle Taper vert. & horiz. remote handwheel, spindle oil coller, 2 Screw Conveyors & lift up.

Stock Number:
3800
Model:
SB316YM
Serial No.:
18398
Machine Age:
2019
Condition:
New
New-Used:
Used
Specifications:
"X" Travel:
120.5"
"Y" Travel:
90.5"
"Z" Travel:
31.5"
Distance between columns:
66.9"
Table size:
118." x 59"
Table load capacity:
22,000 lbs.
Spindle Taper:
Cat #50 Big Plus
Spindle Power:
30/35 HP
Spindle Speeds:
10 - 6,000 RPM
No. of gears:
Two
Rapid feed rate X & Y:
944 IPM
Rapid feed "Z":
590 IPM
Max cutting feed rate:
394 IPM
Automatic tool changer capacity:
60 Tools
ATC time tool to tool:
8 seconds
Machine weight. Approx.:
68,000 lbs.
Machine Dimensions:
281" L X 183" W X 171" H
Coolant through spindle Vert. & Horiz.:
580 PSI
Right angle head indexing:
1 degree
