19-4
3254832
used
(7)
$0.00

Description

'

Basic Information

Model: 19-4
Manufacturer: Summit
Serial #: 3254832
Location: Huntington Park, CA
Year Built: -

Specifications

Swing Over Bed: 19"
Swing In Gap: 29"
Swing Over Cross Slide: 11"
Distance Between Centers: 80"
Spindle Speeds (21): 22- 1,500 RPM
Spindle Nose: D1- 8
Hole Thru Spindle: 4"
Threads:
Inch (64): 0.25- 60 TPI
Metric (64): 0.5- 120 MM
Feeds: 0.0007"- 0.444"
Cross Slide Travel: 11 3/8"
Tailstock Quill Taper: #5 MT
Tailstock Quill Travel: 9 1/2"
Dimensions (L x W x H): 139" x 48" x 73"
Weight: 7,500 Lbs.

Equipped with

  • 3 Jaw Chuck
  • Taper Attachment
  • Tool Post
  • Coolant System
  • Horsepower: 15
'
