Description

Machine Features:

l      5 individually programmable axes

l      Max. ?88.9mm capacity

l      Individually controllable pressure die assists for each bending stack

l      Programmable 2 speeds early mandrel extraction

l      Each axis may be individually programmed during arm return mode

l      SOCO proprietary control software with IPC & Touch Screen

l      Built-in wiper die, pressure die and clamping die seats

l      High accuracy and repeatability (plus/minus 0.1mm /plus/minus 0.1deg for all axes )

l      Ability for 1D Bending 1(*) and Roll Bending (**)

l      Single and multi-stacks models

l      Standard with Automatic Mandrel Lubrication System

l      Centralized greasing and lubrication system for all sliding areas

l (*) Depending on tube O.D. and elongation ratio

l (**) May be added by request  2SV models

Software Features:

l      Automatic springback compensation

l      Recapturing function for short lengths

l      Data entry for both XYZ and YBC coordinates

l      XYZ to YBC coordinates conversion

l      YBC to XYZ coordinates conversion

l      Arm return programming mode (Overmode)

l      Arc Radius calculator for large radius bending

l      Carriage Boost settings page for 1D Bending

l      Ability to use Positive and Gripper Mode Feeding in the same part

l      Fi le management for parts and tooling

l      Data storage of files ( 2 million files , 50 bends per file ) ( * )

l      3D display and rotation of parts

l      Mirroring and image reversal of parts

l      Ability to edit files while Bending

l      Windows platform

l      Self diagnostics + Error messages display

l      Connection and Auto compensation to CMM systems ( ** )

l      Simultaneous opening of files ( 4 files at one time )

l      Programmable mandrel extraction and mandrel lubrication

l      Individually programmable axes

l      Multiple built-in action and bending sequences

l      Built-in internet connection for Remote troubleshooting
