MONARCH VMC 175B VERTICAL MACHINING CENTER

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


VMC 175B
96602B
Machining Centers Vertical Horizontal CNC
Vertical Machining Centers
used
36000 (LB)
1996
$97,500.00

Description

Specifications:

Model                                                   VMC 175B

Control                                                  Fanuc 15M

Year of manufacture                           1996

Serial number                                      96602B
Overall table size                                108 in x 36 in
Rotary table & tailstock                      Yes, Tsudakoma 15 in with 5.5 in bore
Work area                                           76 in x 30 in x 44 in (6 in riser in column)
Table load capacity                            6,000 lbs.
Travels:
X Axis travel (left & right)                  76"
Y Axis travel (in & out)                       30"
Z Axis travel (up & down)                 44 in
ATC                                                   30 tools
Spindle nose to table, min-max       6.1 in to 41.5 in
Quill travel                                          10 in
Rigid tapping                                     Yes
Spindle speeds                                 6,000 rpm.
Spindle drive motor                          35/40 hp.
Feed rate/rapid rate max.                315/600 ipm.
Spindle chuck taper                         Cat 50
Electrics                                             440/3/60 (step up transformer incl).
Manuals                                             Yes
Approx. shipping weight                  36,000 lbs.

Price: $ 97,500.00 Houston, Texas. SUBJECT TO PRIOR SALE
Condition: Very good.
Delivery: Stock. Terms: Payment due prior to shipment.
