MODERN VMC-1300 CAT-50 TAPER HEAVY DUTY VERTICAL MACHINING CENTER (USED)

SPECIFICATIONS:

TABLE

 TABLE SIZE 26 in X 59 in

 TABLE HEIGHT 33.5 in

 T-SLOT (W/PITCH/NO) 18 x 110 x 5 MM

MAX. TABLE LOAD 3,300 LBS

TRAVEL

 X AXIS 51 in

 Y AXIS 25.5 in

 Z AXIS 28 in

 SPINDLE NOSE TO TABLE 3 in to 31.5 in

SPINDLE

 SPINDLE TAPER ISO CAT-50

 SPINDLE SPEED 6,000 RPM 2 SPEED GEARBOX

 MOTOR SPEED (RATED/MAX.) 9000 (FAGOR)

 MOTOR OUTPUT 25 HP (FAGOR)

 GEAR RATIO 1.1 : 1 / 4.4 : 1

 FRONT BEARING (ID/OD) 2.75 in/4.33 in

 REAR BEARING (ID/OD) 2.36 in/3.73 in

 TRANSMISSION  GEARBOX

 TOOL CLAMPING FORCE 2600 LB F



Condition Used

Stock CALGARY
