MITSUBISHI FX-10K WIRE EDM

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images


FX-10K
Electrical Discharge Machining EDM
Wire Cut EDM
used
4070 (LB)
2000
$0.00

Description

This machine is designed for superior accuracy and rigidity. Equipped for submerged cutting with automatic wire threader and dielectric system.

Specification                                                                           Description

Machining Stroke (X x Y x Z)                                            13.77" x 9.84" x 8.66"

Table Size                                                                            24.80" x 20.86"

Maximum Workpiece Size                                                    31.49" x 22.63" x 8.66"

Maximum Workpiece Weight                                                 1,168 Lbs

Taper Capacity                                                                   15 degrees +/- in 4"

Wire Diameter Capability                                                       .004" - .012"

Wire Guides Included                                                       .010" Dia

Maximum Amperage                                                                 40 Amps

Approximate Overall Dimensions                                       92" x 91" x 90"

Approximate Machine Weight                                                 4,070 Lbs

Equipped With:

* Mitsubishi 32 Bit CNC 5 Axis Control w/ 14" Color CRT * Automatic Wire Threader (AF3) * Submerged Cutting Capability * Anti-Electrolysis Power Supply * Power Master with FC Override * Advanced Hand Pendant * Three-Sided Stainless Table * Dielectric Filtration System * Electric Chiller * All Available Manuals and Accessories

Stock Number: 0801

Condition: As Is, Where Is
