HURCO VMX42I MACHINE SPECIFICATIONS
Travel
X-Axis
42 in
Y-Axis
24 in
Z-Axis
24 in
Spindle Nose to Table
6 in to 30 in
Table
Dimensions
50 in x 24 in
Max Load
3,000 lbs
T-slot
5 x .71 in on 3.94 Centers
Spindle
Spindle Type
Spindle Speed
12,000 RPM
Spindle Torque
175 ft/lbs
Spindle Motor
24 HP
Coolant Thru Spindle
Optional
Spindle Taper
CAT 40 / Big Plus
Feed Rate
Rapid Traverse (X/Y/Z)
1,378/1,378/1,181 ipm
ATC
Capacity
30 Tools
Max. Tool Diameter
3.1 in
Max. Tool Length
11.8 in
Tool to Tool ATC Time
2 seconds
Requirements
Air Pressure
5 CFM @ 80-100 psi
Power Consumption
26 KVA
Machine Net Weight
14,775 lbs
Operating Dimensions
181 in x 152.5 in x 109 in
Side Mounted ATC
Coolant Thru spindle
Renshaw probe
MINT CONDITION
To view more information on the HURCO VMX 42I VERTICAL MACHINE CENTER, including reviews, brand information, photos, videos, and more,
