HAAS TM3P CNC MACHINING CENTER 40 X 26 X 16 XYZ #5650

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


TM3P
Machining Centers Vertical Horizontal CNC
Vertical Machining Centers
used
6200 (LB)
2011
$0.00

Feature Video

Description

DESCRIPTION

Make: Haas

Model: TM3P

Year: 2011



SPECIFICATIONS:

X Axis Travel: 40"

Y Axis Travel: 20"

Z Axis Travel: 16"

Rapid Rate X Axis: 400 IPM

Rapid Rate Y Axis: 400 IPM

Rapid Rate Z Axis: 400 IPM

Table Size: 57.8" x 14.5"

Max Table Load: 1,000 LBS

Spindle Motor: 7.5 HP

Spindle Speed: 6,000 RPM

Spindle Taper: 40 CT

Tool Changer: 10 ATC

Max Cutting 400 ipm

Max Torque 33 ft-lbf

Drive System Direct Speed, Belt Drive

Max Thrust X 2000 lbf

Max Thrust Y 2000 lbf

Max Thrust Z 2000 lbf

Max Tool Diameter (3.5"

Max Tool Weight 12 lbs

Tool-to-Tool (avg) 5.7 s

Chip-to-Chip (avg) 6.5 s

Dimensions: 130" x 88" x 98"

Weight: 6,200 LBS


More on this model

To view more information on the HAAS TM3P CNC MACHINING CENTER 40 X 26 X 16 XYZ #5650, including reviews, brand information, photos, videos, and more,
