HAAS SL-10 CNC LATHE WITH TAILSTOCK

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


SL-10
Stock No. 6475
Lathes and Turning Centers CNC
Slant Bed Turning center
new
(LB)
0
$0.00

Feature Video

Description

Haas SL-10 CNC Lathe with



Tailstock

Stock: 6475 Manufacturer: Haas Model: SL-10



Age: 24>



CONTROL: HAAS CNC



MAX SWING OVER BED: 16.25"



MAX SWNG OVER SADDLE: 8"



MAX TURNING DIAMETER: 11"



MAX TURNING LENGTH: 14"



SPINDLE SPEEDS: 6,000 MAX RPM



SPINDLE DRIVE: 15 HP



HOLE THRU SPINDLE: 2.31"



SPINDLE NOSE: A2-5



HOLE THRU DRAW TUBE: 1.81"



TURRET CAPACITY: 12 STATION



TURRET TRAVELS (X,Z): 6.25" X 14"



RAPID TRAVERSE RATE (X/Z): 1,200 IPM

TURRET INDEX TIME: 1 SECOND (PER 1 TOOL)

TAILSTOCK?: YES



TAILSTOCK QUILL DIAMETER / TAPER: #3MT



TAILSTOCK QUILL TRAVEL: 4.0" HYDRAULIC

TRAVEL



MAX BAR CAPACITY: 1.8"



MAX SWING OVER FRONT APRON: 16.25"

MAX SWING OVER CROSS SLIDE: 8"

CHUCK SIZE: 6.5"



RAPID TRAVERSE RATE: 710 IPM
