HAAS DM-2 VERTICAL MACHINING CENTER.

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


DM-2
1159776
Machining Centers Vertical Horizontal CNC
Vertical Machining Centers
used
(LB)
2019
$0.00

Description

Description & Specifications

PRICE: Loaded on Truck, Our Warehouse, York, PA    $ POR

HMC Stock #19149-C
Machine Serial No. 1159776
Machine Model No. DM-2
New Date: 2019
This machine is on consignment.
Table Size: 34" LR x 15" FB with (3) T-Slots
T-Slot Width: .630"
T-Slot Center: 4.92"
Maximum Weight on Table: 250 Lbs.
X Axis Travel: 28"
Y Axis Travel: 16"
Z Axis Travel: 15.5"
Spindle Nose to Table: 6" Minimum to 21.5" Maximum
Spindle Taper: CAT-40
Spindle Speed: 12,000 RPM
Drive System: Direct Drive
Maximum Torque: 46 ft-lbf @ 1,700 RPM
Maximum Cutting Feed Rate: 1,200 IPM
Rapids on X, Y, Z: 2,400 IPM
Tool Changer Type: SMTC
Tool Changer Capacity: 18 + 1
Maximum Tool Diameter: 2.5"
Maximum Tool Length: 7"
Maximum Tapping Speed: 5,000 RPM
Coolant Capacity: 55 Gallons
Air Required: 4 scfm at 100 PSI
Machine is Wired 3 Phase, 220 Volts
Overall Machine Size: 84" LR x 84" FB x 100" H
Coolant System Size: 36" FB x 84" LR x 45" H
