FERMAT WFT-13 TABLE TYPE CNC 5.1" HBM

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images


NEW MODEL WFT-13 5.1
S/N UNAVAILABLE
Boring Mills
Horizontal, Table Type NC, CNC
new
84000 (LB)
0
$0.00

Description

FERMAT MODEL WFT-13 TABLE TYPE CNC 5.1" HBM

FEATURES

5 AXES - X, Y, Z, W, B RIGID TAPPING

3100 RPM CAT 50 SPINDLE HELICAL INTERPOLATION

54 HP CONTINUOUS SPINDLE MOTOR POLAR COORDINATE PROGRAMMING
33,000 LB. CAPACITY ROTARY TABLE SCALING
B AXIS ROTARY MACHINING SIMULTANEOUS COORDINATE SYSTEM ROTATION
WITH X, Y, Z OR W AXIS CAST IRON BOX WAYS - X, Y, & Z
MANUAL GUIDE i SHOP FLOOR PROGRAMMING Z AXIS COLUMN TRAVEL
AICC (ARTIFICIAL INTELLIGENCE CONTOUR CONTROL)
HIGH SPEED CONTOUR MACHINING
STANDARD EQUIPMENT
MPG (MANUAL PULSE GENERATOR) 2 SPEED GEARBOX
FULL B AXIS ROTARY TABLE - HEIDENHAHN FANUC 32i CONTROL WITH 15" LCD
0.001 DEGREE ROTARY ENCODER FANUC MOTORS & DRIVES
EXTERNAL COOLANT OR 435 PSI COOLANT OPERATOR ENCLOSURE
THRU SPINDLE CHIP CONVEYOR
DUAL B AXIS PINIONS & SERVO MOTORS AUTO LUBRICATION
63" X 71" ROTARY TABLE 32 POSITION ATC
HEIDENHAIN GLASS SCALES - X, Y & Z AXES
SPECIFICATIONS
HEADSTOCK
SPINDLE DIAMETER -------------------------- 5.1"
SPINDLE TAPER ----------------------------- CAT 50
SPINDLE RPM ------------------------------- 10 - 3100
MAXIMUM SPINDLE TORQUE CONTINUOUS, FANUC -- 1,600 FT. LBS.
MAXIMUM SPINDLE POWER CONTINUOUS, FANUC --- 54 HP
WORKING RANGE
ROTARY TABLE DIMENSIONS ------------------- 63" X 71"
MAXIMUM TABLE LOAD ------------------------ 33,000 LBS.
TABLE TRAVEL (X-AXIS) --------------------- 59"
VERTICAL TRAVEL (Y-AXIS) ------------------ 67"
COLUMN TRAVEL (Z-AXIS) -------------------- 47"
SPINDLE TRAVEL (W-AXIS) ------------------- 28.7"
TABLE ROTATION (B-AXIS) CONTINUOUS, HEIDENHAIN
0.001 DEGREE ROTARY ENCODER ------------ 360 DEGREES

STOCK# 74676
