FADAL CNC VERTICAL MACHINING CENTER WITH 64MP CNC CONTROL

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images


VMC 4020B
Machining Centers Vertical Horizontal CNC
Vertical Machining Centers
used
11770 (LB)
2014
$44,500.00

Description

Travel

X-axis Travel (in.)

40

Y-axis Travel (in.)

20

Z-axis Travel (in.)

20/30*

Spindle nose to table (in.)

5-25/5-35*

Spindle center to column (in.)

21.25

Table

Table Dimensions (in.)

47.25 x 19.75

T-Slot Dimensions (in.)

(5) 3.75 x .709 x 1.25

Max. Table Load (lbs.)

1,320

Spindle

Spindle Type

CAT-40

Spindle Speed (RPM)

10,000/15,000

Spindle Torque (ft. lbs.)

175/220*

Spindle Motor (HP) Peak

15/22.5*

Feed

Rapid Traverse Rate X,Y & Z (IPM)

1,000 / 1,000 / 1,000

Ballscrew Diameter X,Y & Z Axis (mm)

40

ATC

Tool Capacity

24/30*/40*

Tool Change Type

Dual Arm

Max. Tool Weight (lbs.)

15

Max. Tool Diameter (in.) (with adjacent tool)

4.9 (3.1)

Max. Tool Length (in.)

13.5

Tool Selection Method

Random

Other

Machine dimensions L x W x H (in.)

109 x 87 x 110

with Chip Auger

155 x 87 x 110

Machine weight (lbs.)

11,770



Price             44,500.00
