FADAL 4020 VERTICAL MACHINING CENTER

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


FADAL 4020 VERTICAL MACHINING CENTER
4020
Machining Centers Vertical Horizontal CNC
Vertical Machining Centers
used
(LB)
1998
$0.00

Description

Description:

  Table Size
 48" x 20"
   Floor to Table Surface
 32"
   T-Slots (No. x Width)
 5 x 0.687" x 3.75"
   Cutting Feed Rate (X/Y/Z)
 0.01" to 400" (600" at 150%)
   Rapid Travel Rate (X/Y/Z)
 900 (X/Y) 700 (Z)
   Maximum Weight on Table
 3,641 lbs

   Axis Drive Motor (X/Y/Z)
 3,800 Lbs. thrust
   Ball Screw Size
 40mm dia (X/Y/Z)
   Longitudinal Travel (X-Axis)
 40"
   Cross Travel
 20"
   Vertical Travel
 20"
   Spindle Nose to Table
 4" - 24"
   Spindle Center to Column
 20"
   Main Motor
 15/20 HP, 11kW
   Spindle Speeds
 75 - 10,000 rpm
   Spindle Taper
 CT-40
   Number of Tools
 21 ATC
   Max. Tool Diameter
 3"
   Max. Tool Length
 15"
   Max. Tool Weight
 15 lbs
   Machine Floor Space Dimensions
 116" x 87"
   Machine Height
 95" (114" Max.)
   Air Pressure Requiered
 80 psi, 15 scfm
   Power
 45 Amps, 230/440 VAC, 3-Phase

Specifications:
Manufacturer Fadal
Model 4020
Year 1998
Condition Used

More on this model
