Type: 5-Axis or More CNC Lathes
Category: Lathes
Manufacturer: DMG MORI
Model: NTX 1000
Condition: Used - Excellent
Stock #: 3188
Status: For Sale
Description:
DMG Mori Seiki NTX1000 2nd Generation
Maximum Workpiece diameter 16.9 in
Maximum workpiece length 31.5 in
Maximum bar diameter 2.6 in
Maximum X-axis travel 17.9 in
Maximum Y-axis travel 8.3 in
Maximum Z-axis travel 31.5 in
Simultaneous 5-axis machining of complex parts with the direct drive motor
Installed in the B-axis
The B-axis rotation range of 240 deg and rotation speed of 100 rpm, the X-axis
Travel of 17.9 in
Equipped with a Capto C5 tool spindle as standard, max. spindle speed of
12,000 rpm
Thoroughly controlled thermal displacement by cooling oil circulation in the body
High-rigidity bed and linear motion guide achieve high rigidity
Control F31iB5 with CELOS
CELOS ERGOline Touch
(Spindle 1) through-spindle hole dia. 73 mm, 5,000min-1 (bar work capacity dia. 65 mm)( for FANUC)
Standard spindle (spindle 2) 11/7.5 kW, 6,000min-1 (for FANUC)
(Spindle 1) KITAGAWA 8IN. Hollow chuck BB208A621
(Spindle 1) Hollow Cylinder set for KITAGAWA 8in. Chuck BB206A621 (without chuck body)
(Spindle 2) KITAGAWA 6IN. Hollow chuck BB208A621
(Spindle 2) Hollow Cylinder set for KITAGAWA 6in. Chuck BB206A621 (without chuck body)
High-speed tool spindle, 20,000 min-1, 9/5.5 kW, 49.4 Nm (15%ED)/21.9 Nm (C5/HSK-A50)
Capto C5
Tool spindle full indexing specifications (STD)
10 Station Bolt-Tightened Turret, milling specifications (10,000 min-1, 1.5/1.2 kW, 4.8/2.3 nM)
(Turret 2) (for FANUC)
Drilling with the tailstock (live center specifications)
Tool storage capacity 76 tools (Capto C5)
Usable Coolant Type: Water-Soluble Coolant
Chip Conveyor (Right Discharge, hinge type + drum filter type)
Interface for Super-High-Pressure Coolant System (7MPa, Constant Pressure) (Through-spindle coolant system for tool Spindle)
Through-spindle coolant/ air (switching specifications)
Coolant Chiller
Coolant Gun
Air blow for chuck (Counter Spindle)
Interface for Mist collector (duct only, dia. 200mm)
Manual in-machine tool presetter (removable type) (STD)
In-machine workpiece measuring system radio signal transmission type touch sensor (RENISHAW, RMP600)
Signal lamp 4 colors (Red, yellow, green, blue)
Automatic Door
Interface for Bar Feeder (LNS) (multiple)
Multi dry filter
Voltage of Customer Factory 220 V
Frequency 60Hz
Setting Unit Inch
Alternating speed
3D Quick SET
Addition of optional block skip (soft key type 2-9)
X-axis Direction JIS / ISO standard
Equipped with:
Milling head has Y axis, Turret does not have Y axis
35 Milling tool holders per machine 8 to 10 tool holders for turret per machine
Tool Holders Only NO cutting tools
Approx Run times between 4500 hrs to 6000 hrs
Overall dimensions approx.. 178.5 in x 100.1 in x 101.8 in High for each machine
Weight for each machine 25,353 lbs approx..
