DALIAN
CNC FLAT-BED LATHE
S/N MW0128199
Unknown
---Unknown---
used
()
0
$0.00

Description

NEW DALIAN CNC FLAT-BED LATHE MODEL CKE6150Z/1500
FEATURES:
FANUC 0i-TD CONTROL
FANUC MANUAL GUIDE
VERTICAL 6 STATION PROGRAMMABLE TURRET
WIDE 15.7" BED
VARIABLE AC SPINDLE DRIVE MOTOR
PROGRAMMABLE 3 RANGE HEADSTOCK
CONTROL MOUNTED ON LONGITUDINAL RAIL/TRACK FOR EASY POSTIONING
HEAVY-DUTY CONSTRUCTION WITH CAST IRON BASE
X AND Z AXES BALL SCREWS
FANUC SERVO AXIS DRIVE & MOTORS
ANTI-FRICTION TURCITE-B WAY COATING
FULLY ENCLOSED, INTERLOCKING GUARDING
AUTOMATIC LUBRICATION OF SLIDE WAYS AND BALL SCREWS
STANDARD EQUIPMENT:
10" 3 JAW CHUCK 6 STATION ELECTRIC TURRET
FANUC 0i TD CONTROL FANUC MANUAL GUIDE 1 FUNCTION
FANUC X/Z AXIS SERVO MOTION DRIVE MANUAL TAILSTOCK
AC INVERTER SPINDLE MOTOR AND DRIVE FOLLOW REST
STEADY REST FULLY ENCLOSED GUARD
DEAD CENTER FOR TAILSTOCK ANTI-VIBRATION PADS
TOOL KITS DOOR SAFETY INTERLOCK
LIVE CENTER
SPECIFICATIONS:
CAPACITY:
MAXIMUM SWING OVER BED -------------------- 19.6"
MAXIMUM SWING OVER CARRIAGE --------------- 11"
MAXIMUM LENGTH OF WORKPIECE --------------- 59"
WIDTH OF GUIDEWAY ------------------------- 15.7"
MAXIMUM TRAVEL ON X AXIS ------------------ 11.02"
MAXIMUM TRAVEL ON Z AXIS ------------------ 56.3"
HEADSTOCK:
SPINDLE NOSE ------------------------------ D8
SPINDLE BORE ------------------------------ 3.23"
SPINDLE SPEEDS ---------------------------- 7 - 135 RPM
------------------------------------------ 30 - 550 RPM
------------------------------------------ 110 - 2200 RPM
TAPER OF SPINDLE BORE --------------------- 1:20
CHUCK SIZE -------------------------------- 10"
SPINDLE MOTOR ----------------------------- 10 HP
FEEDS:
RAPID TRAVERSE ON X AXIS ------------------ 236.2 IPM
RAPID TRAVERSE ON Z AXIS ------------------ 393.7 IPM
