Specifications Max. cutting cap. 90 deg, round: 16.25 in Max. cutting cap. 90 deg, square:
16.25 in x 16.25 in Blade dimensions: 15 ft x 1-1/2 in x .050 in Blade guides:
Carbide & roller bearing Guide arm (manual / powered):
Manual Blade speeds: 69 - 551 FPM
Number of speeds: Infinite Blade motor: 7 H.P.
Blade drive type: Motor to pulley Blade tension type: Hydraulic Coolant type:
Flood Coolant tank capacity: 33 Gallons
Maximum feed length: 16 in
Number of multi indexes: 3
Maximum weight load: 6,600 Lbs.
Vise type: Hydraulic Roller bed: 76 in
Voltage: 220 / 440 Currently Wired: 220 Volt 3 phase
Dimensions: 99.5 in x 69 in x 50.25 in
Weight: 4,300 lbs
EQUIPPED WITH:
Overhead bundling clamps
Rapid decent of saw head
Chip Conveyor
Split front vice Vertical rollers
Variable vice pressure
Powered blade chip brush
Infeed Conveyor: 76 in x 28 in x 31 in, 500 lbs. capacity
Manufacturer DAITO
Automatic HZ saw
Model GA 400 & 410
Year1984
Condition Used
Serial Number34KB503D3
