CNC DOUBLE END TURNING MACHINE

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images


Tecno Wasino JD-1
Stock Number: 3050
Lathes and Turning Centers CNC
Twin Chuck (Spindle) machines
used
3300 (LB)
2005
$0.00

Description


Capacity

Maximum
swing dia. 9-27/32in

Nominal
workpiec (D x L) 1in x 1in

Maximum
workpiece diameter 1-1/2in

Maximum
workpiece length 2in

Distance
between centers -

Bar
capacity 63/64in 1/2in

Main
spindle headstock

Center
height from floor 39in

Main
spindle nose 100 (4) flat nose

Main
spindle bore 1-3/4in

Main
spindle front bearing ID 2-15/16in

Number
of main spindle speeds Indinitely variable

Maximum
main spindle speed Min-1 6000

Standard
main spindle chuck Collet chuck SAD-25

Standard
main spindle chuck bore 63/64in

Subspindle
headstock

Subspindle
nose AS2-50

Subspindle
bore -

Subspindle
front bearing ID 1-3/8in

Number
of subspindle speeds Infinitely variable

Maximum
subspindle speed Min-1 6000

Standard
subspindle chuck Collet chuck TC-13

Standard
supspindle chuck bore 1/2in

CNC
feed axes

X-axis
(cross slide) travel 3-1/8 + 3/16in

Z-axis
(saddle) travel 4-15/16 + 3-3/4in

B-axis
(subspindle) travel 9-27/32in

X-axis
rapid traverse speed m/min. (fpm) 15 (49.2)

Z-axis
rapid traverse speed m/min. (fpm) 15 (49.2)

B0axis
rapid traverse speed m/min. (fpm) 15 (49.2)

Turret
Turret
type 8-statoin drum

Number
of attachable tools 8 pcs

Standard
tool shank 25/32in

Boring
tool shank diameter 1in

Maximum
turret swing diameter 13in

Motors
Main
spindle motor, cont./30min. 5/7.5 HP

Subspindle
motor, cont./15 min. 0.75/1.5 HP




Dimensions
of machine 51in x 50in

Height
70 - 7/8in

Machine
gross weight 3300 lbs approx.
