Type: Shears, Power Squaring
Manufacturer: CINCINNATI
Model: 1808
Condition: Used - Good
Stock #: 3161
Status: For Sale
Serial #: 37324
Description:
Capacity 8 x 1/4" Mild Steel
Length of Knives 84"
Distance Between Housings 83"
Gap 18"
Rake Angle 1/4" per Foot
Holddowns 9 (Hydraulic)
Holddown to Knife Edge 5/8"
Distance Under Holddowns 1/2"
Ram Adjustment 11/16"
Floor to Top of Bed 32"
Stroke per Minute - Approx. 60
Main Drive Motor 7.5HP/1610RPM 220/440/3/60
Approximate Overall Dimensions 11L x 74"W x 78"H
Approximate Weight 15,000 Lbs.
Equipped With:
Squaring Arm
Push buttons for Start and Stop
Automatic Oil Lubrication
Front Operated Power Back Gauge
Specifications:
Capacity 8 x 1/4" Mild Steel
Length of Knives 84"
Distance Between Housings 83"
Gap 18"
Rake Angle 1/4" per Foot
Holddowns 9 (Hydraulic)
Holddown to Knife Edge 5/8"
Distance Under Holddowns 1/2"
Ram Adjustment 11/16"
Floor to Top of Bed 32"
Stroke per Minute - Approx. 60
Main Drive Motor 7.5HP/1610RPM 220/440/3/60
Approximate Overall Dimensions 11L x 74"W x 78"H
Approximate Weight 15,000 Lbs.
Equipped With:
Squaring Arm
Push buttons for Start and Stop
Automatic Oil Lubrication
Front Operated Power Back Gauge
