Stock Number:
3779
Model:
Robofil 310
Serial No.:
4.2453
Machine Age:
1994
Condition:
Good
New-Used:
Used
Specifications:
Max. work piece size:
33.5" x19.7 x 15.75" thick
Max. work piece weight:
1,100 lbs.
Travel "X" Axis:
15.7"
Travel "Y" Axis:
9.8"
Travel "Z" Axis:
15.75"
Stroke "U" Axis:
15.7"
Stroke "V" Axis:
9.8"
Wire Diameter Range:
.004" to .012"
Taper "U" & "V" axis:
+/- 30 degrees
Speed of Movement:
0 to 35.4" IPM
Power Consumption:
10 KVA
WIRE CIRCUIT:
Programmable Feed Wire Feed Rate:
.13" to 9.84" IPS Second
Programmable Wire Tension:
.03 to 2 kg
Threading:
Standard
Diameter of Wire for Threading:
.1, .15", .185" & .2"
Rethreading:
Standard
Number of Filters:
8
Dielectric Capacity:
250 liters
Ion Exchanger Capacity:
21 liters
Auto. Deionization Regulation:
Standard
Programmable Injection:
4 levels
Auto Restart:
Standard
Max. Cutting Speed:
23.25 Sq. in/hour
Intergrated Technology CT EXPERT:
Auto Choice of generator setti
Taper Modes:
4
Machine Dimensions:
72" x 64" x 88"
Machine Weight:
5,500 lbs.
