Basic Information

Model: 1A

Manufacturer: Carlton
Serial #: 3546
Location: Painesville, OH
Year Built: -

---

Specifications

Arm Length: 4
Column Diameter: 9"
Spindle Speeds (9): 60- 1,500 RPM
Spindle Nose: #4 MT
Spindle Quill Travel: 12"
Spindle Quill Feeds (6): 0.006" - 0.025"
Column To Spindle: 9" - 48"
Spindle To Base: 14" - 53"
Dimensions (L x W x H): 96" x 32" x 90"
Weight: 6,250 Lbs.

---

Equipped with

• Power Elevation
• Box Table
• Horsepower: 3

Basic Information

Model: 1A

Manufacturer: Carlton
Serial #: 4308
Location: Painesville, OH
Year Built: -

---

Specifications

Arm Length: 4
Column Diameter: 9"
Spindle Speeds (9): 60 - 1,500 RPM
Spindle Nose: #4 MT
Spindle Quill Travel: 12"
Spindle Quill Feeds (6): 0.006" - 0.025"
Column To Spindle: 9" - 48"
Spindle To Base: 14" - 53"
Dimensions (L x W x H): 100" x 44" x 102"
Weight: 6,250 Lbs.

---

Equipped with

• Power Elevation
• Box Table
• Coolant System
• Horsepower: 3
