Abrasive Belt Width: 950mm
Working Height: 950mm
Workpiece Thickness: 0.5 to 120mm
Abrasive Belt Width: 970mm
Abrasive Belt Length: 1900mm
First Drive (Abrasive Belt)
Abrasive Belt Drive: 12.5/16kW
Abrasive Belt Speed: 9 / 18 m/sec
Diameter of Contact Roller: 200mm
Second Drive (7 Brushes)
Brush Drive Brush Roller: 11 kW
Top Brush: 11 kW
Brush Speed Brush Roller: 15m/sec
Top Brush: 6m/sec
Diameter of Brush Brush Roller: 200mm
Top Brush: 150mm
Third Drive (7 Brushes)
Brush Drive Brush Roller: 11 kW
Top Brush: 11kW
Brush Speed Brush Roller: 15m/sec
Top Brush: 6m/sec
Diameter of Brush Brush Roller: 200mm
Top Brush: 150mm
Feed
Conveyor Belt Length: 3300mm
Width: 950mm
Feed Drive: infinitely variable 1.5kW
Height Adjustment: 0.42kW
Blowoff fan for drying workpieces
Wet type debris/dust collection system with paper filtration
PLC Control
Electrical: 440 volt / 3 phase
Overall Dimensions: (Approximate) 110 in F-B x 89 in L-R x 82 in H
