BLANCHARD #42HD-84, 84" GEARED HEAD VERTICAL SPINDLE ROTARY SURFACE GRINDER, REMANUFACTURED W/1 YR WARRANTY

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


#42HD-84
Grinders
GRINDERS, SURFACE, ROTARY TYPE (VERTICAL SPINDLE)
used
75000 (LB)
1970
$249,500.00

Description

SPECIFICATIONS:

STOCK #17079

CONDITION: GOOD

Chuck Dia.: 84 inches

Spindle (Horz/Vert): No Specs Attached

Power: 200 horsepower

Swing: 87 inches

Under Wheel: 24 inches

Table Speeds: No Specs Attached

Grinding Wheel Width: No Specs Attached inches

Table Motor Horsepower: No Specs Attached horsepower

Grinding Wheel Dia.: 42 inches

CNC Control: no

Type of CNC Control: No Specs Attached

Dimensions: No Specs Attached

Weight: No Specs Attached ounces

Basic Machine Specifications, Subject to Verification

84" Magnetic Chuck (72" Diameter Magnetic Poles)

Approximately .500" "Chuck Life"

87" Swing Inside Water Guards

24" Maximum Height Under Wheel

42" Grinding Wheel

200 HP Main Spindle Drive,240/480 Volt, Wired 480 Volt

(4) Table Speeds of 3, 4.8, 7.8, 11.9 RPM

.008" to .096" Per/Min Variable Vertical Downfeeds

Equipped With:

Power Rapid Raise and Lowering of Head

Hardened Bed Ways

Water Guards

Oil Lubrication

Automatic Lubrication

1/2" Magnetic Chuck Life

Grinder Dimensions (Aprox.) 240.57" L x 108" W x 160" H

Coolant Dimensions (Approx.) 264" L x 96" D x 105" H

Weight Approximately: 75,000 Lbs.


Price: $249,500.00 "As-Is, Taken From Service, inspected under power in our warehouse"
