Sheet-W: 60 in
Sheet-L: 120 in
Wattage: 6000 w
X-Travel: 121 in
Y-Travel: 61 in
Z-Travel: 3.94 in
Weight: 28,660.00
Specifications
LC F1 3015 F1 NT
Travel Method
Stationary table, X, Y and Z-axis movement for cutting head
Control Method
X, Y and Z simultaneous 3 axis control
Drive Motors
Linear
Maximum Sheet Size
60 in (Y) x 120 in (X)
Maximum Axis Travel
61 in (Y) x 121 in (X) x 3.94 in (Z)
Maximum Axis Positioning Speed
4,724 IPM (6,681in/min 45 deg vector)
Maximum Speed Z-Axis
4,724 inches per minute
Positioning Accuracy
0.0004 in for the entire table
Acceleration
X, Y: 1.5G Z: 3G
Cutting head
Cartridge-type
Z-axis sensor
HS-2007 (Anti-plasma, noise resistant)
Maximum Material Weight
2,000 lbs.
Assist Gas
Automatic 4 ports with NC pressure Control
Machine Weight
28,660 lbs. (including oscillator)
Electrical Requirements
208V, 3 Phase, 60Hz
Laser Power
6000 watts
CNC Controller
Model AMNC-F
Display
LCD Color Graphics Display
Control Function
X, Y, Z-Axis Simultaneous and Focus Lens B-axis, Adaptive Optic and Laser Power control (CW, Gated Pulse, Pierce Routines etc.)
Data Input Method
Touch screen, Keyboard, Ethernet, Wireless, CD, USB, 3.5 in Floppy disk
Minimum Command Unit
0.0001 in (X, Y, Z)
Minimum Travel Unit
0.0001 in (X, Y, Z)
Standard Memory
2 MB
Hard Drive
10 GB
Operating Modes
Automatic and Manual
Display Modes
Program Contents, Position Information, Program Check, Settings, Parameters, Beam Diameter Compensation, Assist Gas Status, Self Diagnostics
Interlock Displays
Cooling Water Status, Gas Pressure Status, Vacuum Status, Turbo Blower Malfunction, Shutter Status, Beam Power, Resonator Discharge, Door Open, WACS
To view more information on the AMADA LC-3015F1NT LASER CUTTING SYSTEM, including reviews, brand information, photos, videos, and more,
