1.1 Motion Package
Travel Method
Stationary table, X, Y and Z-axis movement for cutting head
Control Method
X, Y and Z simultaneous 3 axis control
Drive Motors
Fanuc AC servo motors
Maximum Sheet Size
61" (Y) x 122.8" (X)
Maximum Axis Travel
61" (Y) x 122.8" (X) x 7.87" (Z)
Maximum Axis Positioning Speed
3,150 inches per minute (80m/min) per axis (4,554 inches per minute 45o
vector.
Maximum Speed Z-Axis
2,362 inches per minute
Positioning Accuracy
0.0004"/20"
Maximum Material Weight
1,875 lbs.
Assist Gas
4 ports with NC pressure Control
Machine Footprint
385" x 107"
Machine Weight
12 Metric Tons
Electrical Requirement
208V, 3 Phase, 60Hz, 10KVA
1.2 CNC Controller
Model
Fanuc 160iL - 32 Bit
Display
LCD Color Graphics Display
Control Function
X, Y, Z-Axis Simultaneous and Focus Lens B-axis, Adaptive Optic and Laser
Power control (CW, Gated Pulse, Pierce Routines etc.).
Data Input Method
Manual (MDI), Edit, DNC, or 3 " PC compatible disk.
Minimum Command Unit
0.0001" (X, Y, Z)
Minimum Travel Unit
0.0001" (X, Y, Z)
Standard Memory
512K (1280m)
Operating Modes
Automatic, MDI and Manual
Display Modes
Program Contents, Position Information, Program Check, Settings, Parameters,
Beam Diameter Compensation, Assist Gas Status, Self Diagnostics
Interlock Displays
Cooling Water Status, Gas Pressure Status, Vacuum Status, Turbo Blower
Malfunction, Shutter Status, Beam Power, Resonator Discharge, Door Open, WACS.
Electrical requirements
See Motion Package
To view more information on the AMADA GEMINI FO-3015, 4,000 WATT, APPROX.56,000 HRS,MFG:2001 OUR STOCK NUMBER: 11589, including reviews, brand information, photos, videos, and more,
