AGIE SPIRIT 2 CNC SINKER

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images


Spirit 2
Electrical Discharge Machining EDM
Die Sink EDM
used
2860 (LB)
2006
$0.00

Feature Video

Description

Agie is the premier manufacturer of electrical discharge machining systems and are partners to the best EDM shops in the world -- with over 15,000 users and an installed base of 40,000 wire-cut and die-sinking EDM systems is testament to their success. A video of this machine can be seen on YouTube at: https://youtu.be/5B80NOHSIPQ

Request a quote on stock# 1430

Specification Description

Travels X, Y, Z 11.8" x 9.85" x 9.85"

Bath Level - Programmable 8.85"

Table Size 15.7" x 11.8"

Max Workpiece Dimensions 24.8" x 15.7" x 7.3"

Maximum Workpiece Weight Capacity 440 lbs

Distance Table to Quill (min/max) 7.5" - 17.4"

Dielectric Capacity 80 Gallons

Machine Dimensions (LxWxH) 73" x 83" x 93"

Control Dimensions (LxWxH) 30" x 21" x 69"

Machine Weight 2,860 lbs

Equipped With:

* Agie Windows Based PC Control w/15" Color LCD * Full Integrated C-axis (System 3R Macro) * 4 Position Tool Changer * Remote Control Jogbox * Agie APG Generator * 72 Peak Amps * Automatic Current Correction (ACC) * Automatic Controlled Optimization (ACO) * AgieBril - Fine Finish Circuitry * Equimode - 3D Machining Capability * Automatic Measuring Cycles * Programmable Polarity * Resident Agie Proven Erosion Technology * Color Graphics * 20GB Hard Drive * Programmable Flush Ports (Tank-3,Quill-1) * Heat Exchange Capability * Transformer * All Original Manuals and Accessories

Stock Number: 1430

Condition: As Is, Where Is
