Maximum Swing: 13.74"
Maximum Distance Between Centers: 39.37"
Maximum Grinding Capacity: 13.74"
Height of Centers: 6.89"
Power Requirements: 13.4HP
Z-Axis Travel: 43.9"
Table Swivel: 9°
X-Axis Travel: 10.24"
Max Grinding Wheel (Left): 15.75" x2.48" x5.00"
Max Grinding Wheel (Right): 8.86" x0.79" x3.00"
Wheelhead Motor Output: 5.9HP
Wheelhead Swivel: 200°
Internal Spindle Carrier: 3.15"
Workhead Swivel: -30° / +120°
Spindle Speeds: 5-500 RPM
Internal Taper of Spindle: #5MT
Workhead Motor Output: 3.2HP
Tailstock Taper: #4MT
Tailstock Sleeve Retraction: 1.18"
EQUIPPED WITH:
Kelco 70 CNC Control System
Movomatic CR257 O.D. Measuring Device
Coolant System
Magnetic Separator
