SPECIFICATIONS:
SWING OVER FRONT APRON ............ 16.25"
SWING OVER CROSS SLIDE ............ 8"
CHUCK SIZE ........................ 6.5"
STANDARD BAR CAPACITY ............. 1.75"
MAX. CUTTING DIAMETER ............. 11"
MAX. CUTTING LENGTH ............... 13"
SPINDLE SPEED ..................... 6000 RPM
PEAK SPINDLE HORSEPOWER ........... 15HP
SPINDLE NOSE ...................... A2-5
SPINDLE BORE ...................... 2.31"
X-AXIS TRAVEL ..................... 6.25"
Z-AXIS TRAVEL ..................... 14"
RAPID TRAVERSE RATE ............... 710 IPM
NUMBER OF TURRET TOOLS ............ 12
TOOL SIZE, OD ..................... 0.75"
APPROX. WEIGHT .................... 5,500 LBS
EQUIPPED WITH:
- HAAS CNC CONTROL
- 6" 3-JAW CHUCK
- 12 POSITION TURRET
- CHIP AUGER
- ALL AVAILABLE TOOLHOLDERS AND MANUALS
