ENSIS Fiber Laser Cutting System
The Amada ENSIS-3015AJ is a fiber laser cutting system featuring
Amadas proprietary ENSIS technology, which offers the ability to
cut both thick and thin material with excellent cut quality. This
technology also allows the user to easily switch between material
thicknesses and types. By combining the ENSIS technology with
Amadas proven laser cutting knowledge, this is Amadas most
versatile fiber laser cutting system.
Laser Specifications
Motion Package:
Travel method: Stationary table X,Y and Z axis movement for
cutting head
Control method: X,Y and Z simultaneous 3-Axis control
Drive motors: Fanuc AC Servo motors
Maximum sheet size (X,Y): 120" x 60"
Maximum axis travel (X,Y,Z): 121" x 61" x 3.93"
Maximum positioning speed (X,Y)
Per axis: 4,724 inches per minute
45 degree vector: 6,693 inches per minute
Maximum speed Z-axis: 4,724 inches per minute
Repeatability: +/- 0.0002"
Maximum material weight: 2,000 lbs.
Maximum material thickness
Mild steel: 1.0"
Stainless steel: 1.0"
Aluminum: 0.750
Assist gas: 4 ports with NC Pressure control
Electrical requirements: 200V, 3 Phase, 60 Hz
Fiber Laser resonator (Engine):
Model: AJ6000 with ENSIS Technology
Resonator style: LD Excited Yb fiber
CW output power: 6 KW
Laser Wavelength: 1.08 microns
CLICK ON THIS LINK FOR ONLINE BROCHURE:
