REFERENCE NUMBER: 16035
MODEL #: 750.6
SERIAL #: 426
50 TONS MAXIMUM CAPACITY
6 ft OVERALL BED LENGTH
6 in STROKE
14 in OPEN HEIGHT
8 in THROAT
52 in BETWEEN HOUSINGS
2600 MAXIMUM PSI
YEAR: 1983
6 ft DIE HOLDER MOUNTED TO BED
SHORTER UPPER PUNCH AND LOWER DIE
FOOT PEDAL CONTROL
ADJUSTABLE POSITION STOPS
FINE HAND WHEEL ADJUSTMENT FOR BOTTOM OF STROKE
MANUAL RAM BALANCING ADJUSTMENT
LEFT TO RIGHT
10 HP MOTOR 208/230/460/3/60
PRESENTLY WIRED 460
83 in LR x 45 in FB x 74 in TALL APPROXIMATE DIMENSIONS
6500 LBS APPROXIMATE WEIGHT
GOOD CONDITION
