2D Specifications 4.0kW
Machine Structure Flying Optics
Maximum Workpiece Dimensions 60.039 in x 120.078 in
Maximum Workpiece Weight 2,050 lbs
Machine TravelsX axis 122.046 in
Y axis 62.2 in
Z axis 5.91 in
Work Table Height 35.43 in
Maximum Material Thickness * Mild Steel 1000 in
Stainless Steel 0.750 in
Aluminum 0.625 in
Motion Drive System Design X, Y axisRack and Pinion Drive
Z axis Belt Drive
Number of Control Axes 4
Rapid Travel Speed X, Y, Z axis 2,362 ipm
Positioning Accuracy X, Y axis 0.002 in/19.68 in
Z axis 0.0004 in/3.94 in
Repeatable Accuracy X, Y, Z axis 0.0012 in
Maximum Processing Feedrate X, Y axis 2,362 ipm
Total Electrical Requirement 56 kVA
Installation Dimensions W x D245 in x 460 in
Machine Unit Dimensions W x D x H 119.5 in x 392.1 x 95.3 in
Machine Unit Weight 29,762 lbs
CNC Type MAZATROL PreviewG
CPU 64 bit
Display Screen 19 in SXGA Color (TFT)
Memory Capacity 16 GB (program memory capacity: 1 GB)
Position Detection System Encoder
Minimum Command Unit 0.0001 in
Program Input System EIA/ISO
* Material cutting thickness is dependent on many factors including material
specifications, condition and machine parameters.
All specifications are subject to change.
To view more information on the 4000 WATT MAZAK OPTIPLEX NEXUS 3015 FIBER LASER,MFG:2017, OUR STOCK NUMBER: 12322, including reviews, brand information, photos, videos, and more,
