SPECIFICATIONS:
X-AXIS TRAVEL .................... 30" 762mm
Y-AXIS TRAVEL .................... 16" 406mm
Z-AXIS TRAVEL .................... 20" 508mm
SPINDLE SPEED .................... 8,100 RPM
SPINDLE MOTOR .................... 30 HP
SPINDLE DRIVE .................... INLINE DIRECT DRIVE
SPINDLE TORQUE ................... 90 FT-LB @ 2000 RPM
SPINDLE TAPER .................... CT 40
TOOL MAGAZINE CAPACITY ........... 20 ATC
MAXIMUM TOOL DIAMETER/WEIGHT ..... 3.5" / 12 LBS
RAPID TRAVERSE RATES ............. 1000 IPM
TABLE SIZE ....................... 36" X 14"
TABLE LOAD CAPACITY .............. 3000 LBS
MACHINE DIMENSIONS: .............. 90" x 92" x 104"H
MACHINE WEIGHT: .................. 8,000 LBS
Probe information:
Renishaw A-4071-2001-RBE OMP40 Probe Kit
Modulated (MOD TX/OPT-OFF). OMP40 with
OTS Optical Tool Setter WIPS-R Type
To view more information on the 30"X, 16"Y, 20"Z, HAAS VF2, VERTICAL MACHINING CENTER MFG:2015 OUR STOCK NUMBER: 11713, including reviews, brand information, photos, videos, and more,
