28″/38″ X 240″ TIMEMASTER/GURUTZPE GAP BED LATHE

Add to Your File

Brand: 28″/38″ X 240″ TIMEMASTER/GURUTZPE GAP BED LATHE

Model: SUPER M 350/6000

Serial No. : 2238

Category: Lathes (Manual)

Sub Category: Gap Bed Lathes

Condition: used

Weight: 17500 (LB)

Year Built: 0

Status:

Price: $39,500.00

Feature Video

Description

28 in/38 in x 240 in TIMEMASTER/GURUTZPE GAP BED LATHE

MODEL: SUPER M 350/6000, S/N: 2238, NEW: 1980s

SPECIFICATIONS:

SWING OVER BED 27-9/16 in

SWING OVER CROSS SLIDE 18-1/8 in

SWING IN GAP 38-3/16 in

LENGTH OF GAP 11-7/16 in

DISTANCE BETWEEN CENTERS 240 in

HOLE THRU SPINDLE 5-1/2 in

FRONT & REAR SPINDLE TAPERS D1-11 in CAMLOCK

WIDTH OF BED 16-5/16 in

SPINDLE SPEED RANGE (12) 12 to 900 RPM

TRANSVERSE FEED RANGE (90) .0016 to .066 IPR

CROSS FEED RANGE (90) .0009 to .036 IPR

METRIC THREADS (61) 1 to 112 MM

INCH THREADS (81) 1/4 to 112 TPI

TAILSTOCK TAPER #5MT

TAILSTOCK QUILL TRAVEL 9-7/16 in

APPROXIMATE DIMENSIONS 310 in L x 48 in W x 54 in H

APPROX WEIGHT 17,500 LBS

EQUIPPED WITH:

TAPER TURNING ATTACHMENT

FRONT & REAR CAMLOCKS

9 in CAPACITY STEADY REST

12 in CAPACITY ROLLER TYPE STEADY REST

19-1/2 in 3-JAW CHUCK

15-1/2 in 3-JAW CHUCK

23-1/2 in 4-JAW CHUCK

THREAD DIAL INDICATOR FOR LONGITUDINAL CARRIAGE TRAVEL

RAPID TRAVERSE ALL DIRECTIONS

COOLANT SYSTEM

HARDENED BED

15 HORSE POWER MAIN MOTOR
