24" X 144" CC, LEBLOND, 18" 3-JAW CUSHMAN CHUCK, TAPER ATTACHMENT, STEADY REST OUR STOCK NUMBER: 10666

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


LEBLOND, 18
Lathes (Manual)
Engine Lathes
used
7500 (LB)
1978
$0.00

Description

REGAL "SERVO SHIFT"

NEW: 1978

SPECIFICATIONS:

SWING OVER BED............................. 26"
SWING OVER CROSS SLIDE..................... 18 1/4"
DISTANCE BETWEEN CENTERS................... 144"
SPINDLE NOSE............................... L-2
HOLE THRU SPINDLE.......................... 2 3/16"
SPINDLE SPEED RANGE (12)................... 27 - 1080 RPM
LONGITUDINAL FEED RANGE (48)............... 0.0036" - .0205" IPR
CROSS FEEDS HALF THE VALUES OF LONGITUDINAL
THREADING RANGE ENGLISH (48)............... 2 - 112 TPI
WIDTH OF BED............................... 17"
TAILSTOCK SPINDLE DIAMETER................. 3 1/8"
TAILSTOCK SPINDLE TRAVEL................... 7 1/2"
TAILSTOCK SPINDLE TAPER.................... #5 MT
APPROX. WEIGHT............................. 7500 LBS
APPROX. DIMENSIONS......................... 215" L x 55" W x 60" H

EQUIPPED WITH:

TAPER TURNING ATACHMENT
REPLACEABLE HARDENED BED WAYS
18" CUSHMAN 3-JAW CHUCK
(1) ONE ROLLER TYPE STEADY REST 7.5" CAPACITY
(1) ONE ROLLER TYPE STEADY REST 13.5"CAPACITY
THREAD DIAL INDICATOR
MICROMETER CARRIAGE STOP
COOLANT SYSTEM WITH REMOVEABLE CHIP PANS
15 HP 3/60/230-440 VOLT MOTOR WITH CONTROLS

SPECIFICATIONS SUBJECT TO VERIFICATION
