Reference #: 8300
Machine Type: CNC Lathes
Year: 2016
Manufacturer: Okuma
Model: L300M
Control: OSP-3000L
Condition: Good - Used
Under Power: Yes
Code: L2150M
Specificatons:
Max Swing Over Slant Bed: 20.47"
Max Swing Over Cross Slide: 14.57"
Max Distance Between Centers: 20"
Maximum Cutting Diameter: 11.81"
Maximum Turning Length: 17.7"
Chuck Size: 10" Kitagawa
Cross Travel (X-Axis): 9.25"
Longitudinal Travel (Z-Axis): 20.47"
Rapid Traverse Rate: 787 IPM
Number of Turrets: 1
Turret Positions: 12
Spindle Nose: A2-8
Spindle Bore: 3.15"
Bar Capacity: 3"
Spindle Speed: 25-3000 RPM
Spindle Drive Motor: 15 HP
Milling Spind Speed: 100-4500 RPM
Miling Spindle Motor: 9 HP
Electrics: 230/3/60
Approximate Machine Dimension: 70" x 100"
Approximate Machine Height: 68"
Approximate Machine Weight: 9000 LBS
Equipped With:
OSP 300L Control
10" Kitagawa Chuck
Chip Conveyor
Full standard package of Live and Static Tool Holders
Comments:
1657 cutting hours
Cutting Mild Steel
it has had a PM every year since, and it is in great condition, runs most days
