2011 DOOSAN VC-430 MACHINING CENTER, MACHINE # 8130

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


VC-430
Machining Centers Vertical Horizontal CNC
Vertical Machining Centers
used
17226 (LB)
2011
$0.00

Description

Reference #:8130
Machine Type:CNC Verticals
Year:2011
Manufacturer:Doosan
Model:VC-430
Control:Fanuc
Condition:Used
Under Power:No
Code:M0185

Table:

  • Table Size: 28" x 19.3"
  • Maximum Table Load: 660 Lbs

Travels:

  • X-Axis Travel: 22"
  • Y-Axis Travel: 16.9"
  • Z-Axis Travel: 22.4"

Spindle:

  • Spindle Speeds (Maximum): 12,000 RPM
  • Spindle Taper: BIG PLUS BT40
  • Main Motor (30 min. / cont.): 25 HP

Tool Changer:

  • Tool Changer Positions: 40 ATC

Rapids:

  • Rapid Traverse (XY/ Z): 1575 / 1417 IPM

Machine:

  • Length: 113.8"
  • Height: 122.4"
  • Width: 94.1" x 37.1"
  • Weight: 17,226 Lbs

Comments:

  • This machine returned to the US from the Shutdown of our Costa Rica
  • Operations. The machine was sent to our operation in Connecticut and they
  • simply do not have need nor do they have the room for it. The machine is not
  • set up, not powered up, and we cannot acquire any information on hours.
  • Machine was operational in Costa Rica when disconnected so there is every
  • anticipation that the machine will power up and operate.
  • ** Reasonable Offers Considered **
