1997 MITSUBISHI FX10 WIRECUT EDM

Add to Your File

Brand: 1997 MITSUBISHI FX10 WIRECUT EDM

Model: FX10

Serial No. : E2475

Category: Electrical Discharge Machining EDM

Sub Category: Wire Cut EDM

Condition: used

Weight: (KG)

Year Built: 1997

Status:

Price: $0.00

Description

Table:

Table Length: 24.8\"
Width: 20.8\"
Maximum Table Load: 1168 Lbs
Table resolution: .000004\"

Travels:

X-Logitudinal: 13.77\"
Y-Cross: 9.84\"
Z-Vertical: 8.66\"
Taper U-V Travel: 1.250\"
Taper capacity: +/- 15 Deg in 4\"
Rapid Table Feed: 51.18 IPM
Table Height from Floor: 35.43\"

Tank:

Capacity: 104 Gallons
Power Supply: 50 Amps / 220 Volts
Wire Diameter Range: 0.0078\" - 0.011\"

Workpiece:

Max Workpiece Dimension: 31\" x 22\" x 8.4\"
Distance between platen & table: 35.4\"

Dimensions:

Overall dimensions: 80\"LR x 94\"FB x 78\"H
Weight: 4,070 Lbs

Equipped With:

Wire Threader
Autolube System
Wire Chopper
Radiator Cooler

Comments:

Good operating condition
