1994 FADAL VMC-15XT

Add to Your File

Brand: 1994 FADAL VMC-15XT

Model: VMC-15XT

Serial No. : M0185

Category: Machining Centers Vertical Horizontal CNC

Sub Category: CNC Vertical Turret Lathes

Condition: used

Weight: (KG)

Year Built: 1994

Status:

Price: $0.00

Description

'

Table:

Table Size: 38.5\" x 16\"
Maximum Table Load: 750 Lbs

Travels:

X-Axis Travel: 30\"
Y-Axis Travel: 16\"
Z-Axis Travel: 20\"

Spindle:

Spindle Speeds: 150 - 7,500 RPM
Spindle Taper: 40 Taper
Main Motor: 15 HP
Spindle Nose to Table: 4\" - 24\"

Tool Changer:

Tool Changer Positions: 21 Stations
Maximum Tool Weight: 15 Lbs
Maximum Tool Diameter / w/o Adjacent Tool: 3\" / 6\"

Rapids:

Rapid Traverse: 400 IPM
Cutting Feed Rate: 375 IPM

Equipped With:

RS-232 Port
Rigid Tapping
1,000 Blocks Per Second
Full Enclosure
Coolant System
Tool Life Management
Work Light
Spindle Taper Air Blast
Hi Torque Spindle Motor
Fadal 88HS Control
