1985 KURAKI KBT 1105 DX, BORING MILL MACHINE # 8148

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images


KBT 1105 DX
Boring Mills
Horizontal, Table Type NC, CNC
used
(LB)
1985
$0.00

Description

Reference #:8148
Machine Type:Boring Mills
Year:1985
Manufacturer:Kuraki
Model:KBT 1105 DX
Control:Fanuc 6MB
Condition:Used
Under Power:Yes
Code:B5751

Spindle:

  • Spindle Diameter: 4.3"
  • Spindle Motor: DC 15/20 HP
  • Spindle Speeds: 5-1,200 RPM
  • Spindle Taper: ISO 50

Travels:

  • X-AxisTravel: 78"
  • Y-Axis (Vertical) Travel: 59"
  • Z-Axis (Spindle) Travel: 25.6"
  • W-Axis (Saddle) Travel: 57"
  • Rapid Traverse Rate (X,Y & W): 197 IPM
  • Spindle Quill Rapid Traverse Rate: 126 IPM
  • Cutting Feed Rate: .08 to 78.7 IPM

Table:

  • Table Size: 55.5" x 63"
  • Table Load Capacity: 13,860 lbs.
  • Rotary Table Indexing: 360 Degrees

Dimensions:

  • Length x Width x Height: 264" x 180" x 173"
  • Ball Screw Diameter: 2.48"

Equipped With:

  • Optical Readouts with Precision Scales for Rotary Table
  • Power Draw Bar with Cotter & Draw-Key
  • Centralized Pendant Operational Switch Panel with CRT
  • Way Covers for Saddle & Bed
  • Hardened & Ground Slideways, Gears & Spindle
  • Super Precision Double-Row Cylinder Roller Bearings
  • Fanuc Model 30M DC Servo Motors All Axes
  • Fully Programmable Spindle Speeds and Feeds
