1973 CINCINNATI 750 TON X 20 FOOT HYDRAULIC PRESS BRAKE

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images


750 Ton x 20 Foot Hydraulic Press Brake
B7015
Press Brakes
Hydraulic Press Brakes
used
(KG)
1973
$0.00

Description

Capacity:

  • Tonnage: 750 Tons
  • Bed Length: 20 Foot
  • Stroke: 12\"
  • Open Height: 22\"
  • Closed Height: 10\"
  • Speed High Speed Approach: 110 IPM
  • Speed Medium: 55 IPM
  • Speed Low: 19 IPM
  • Speed Standard Return: 36 IPM
  • Speed Return High Speed: 73 IPM
  • Front Apron Pit Required: 48\"
  • Motor: 60 HP
  • Height: 159\"

Equipped With:

  • Electric Foot Switch
  • Remote Pedestal Control with Palm Buttons

Comments:

  • The machine was fully operational and used every day until it was moved. No
  • reason to assume it will not run. When we purchased the press brake the
  • cylinders were weeping oil (which is common on these machines) and the ram
  • had some dings and tooling marks. There were no major leaks and no obvious
  • operational problems. We welded and re-machined the ram and hold bars. We
  • purchased new packing for the cylinders and installed the packing. Since we
  • did not install the machine, we assume the cylinders will weep until the packing
  • is broken in, so assume the packing will need to be adjusted after start up. Our
  • guarantee is that the machine will run, contingent on being installed per
  • Cincinnati specifications and using the proper fluids, voltages, etc. We cannot
  • guarantee the accuracy of the ram stroke, we tested it before removal and it
  • was good. We assume it will need to be adjusted after installation. Our rigger
  • will be available for phone consultation if needed. It would be up to him if he is
  • willing to travel to assist in installation.
