'REFERENCE NUMBER: 23003A
SN: 16708
MODEL: 27-677
1973
DISTANCE BETWEEN 4.5 DIA. POSTS: 61″ L-R X 30″ F-B
PLATEN AREA: 62″ X 43″
BOLSTER: 61″ X 43″ X 5 ¾”
STROKE: 0-18″
DAYLIGHT OPENING: 28″(W/ 12″ RAM SPACER)
DAYLIGHT OPENING (TOTAL): 40″ MAX
CUSHION TONNAGE: 50.8 TONS@ 100PSI
POWER UNIT(TOP REAR OF PRESS): HYDRAULIC PUMP
25 HP 1800 RPM
230/460/3/60 MOTOR
500 IPM
33 IPM PRESSING TO 150 TONS
75 IPM BREAKAWAY
405 IPM RETURN
PUSH BUTTON OPERATION
STROKE AND PRESSURE CONTROL
DUAL PALM BUTTON OPERATION
PRESSURE GAUGE
To view more information on the 150 TON DAKE HYDRAULIC PRESS, including reviews, brand information, photos, videos, and more,
