  • 143 TON X 122" AMADA HG1303RM ROBOTIC PRESS BRAKE CELL, AMNC 3I,INSTALLED:2022 Our stock number: 12683

143 TON X 122" AMADA HG1303RM ROBOTIC PRESS BRAKE CELL, AMNC 3I,INSTALLED:2022 OUR STOCK NUMBER: 12683

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


143 TON X 122" AMADA HG1303RM ROBOTIC PRESS BRAKE CELL, AMNC 3I,INSTALLED:2022 OUR STOCK NUMBER: 12683
HG1303RM
Press Brakes
CNC Press brake With Robot Loader
used
(LB)
2022
$0.00

Description

Key Features:

- 143- ton capacity servo/hydraulic drive system
- AMNC 3i Control with vertical 18.5" multi-touch display
- 7-axis robot performs consistent unmanned bending operations
- Multi-axis robot with 8-meter track provides versatile loading and unloading

Options:
- Potentiometer back gauge system ensures high-precision bending operations.
- Intuitive offline programming software
- 2x2 gripper station allows robot to automatically change hands between jobs.

Press Brake Specifications:
Tonnage: 143
Open Height: 20.5"
Stroke: 9.8"
Overall Length: 13"
Distance Between Frames: 106.3"
Backgauge: 6 Axis Plus 2 Axis L-Shift
Oil Capacity: 19 gal
Max Approach Speed: 8.7"/sec
Max Bending Speed: 0.79"/sec
Max Return Speed; 9.8"/sec
Control: AMNC 3i

Bending Robot Specifications:
Model: Yaskawa
Load Capacity 176lbs Including Gripper
Axis Configuration: Robot: 6-axis, Traveling 1- axis
Traveling Axis: 26.2
Automatic Gripper Station: Includes 4 Standard Grippers (mechanical and suction-type)

Part Processing Range:
Thickness Range: 0.02" to 0.24"
Max Part Size: 49.2" x 98.4"
Min Part Size: 3.1"x19.7"

More on this model

To view more information on the 143 TON X 122" AMADA HG1303RM ROBOTIC PRESS BRAKE CELL, AMNC 3I,INSTALLED:2022 OUR STOCK NUMBER: 12683, including reviews, brand information, photos, videos, and more,
