143 TON AMADA HDS-1303NT SERVO/HYDRAULIC PRESS BRAKE AMNC-PC 8-AXIS MFG:2006 OUR STOCK NUMBER: 11133

Add to Your File

Product Image
  • Product Images
  • Product Images
  • Product Images
  • Product Images
  • Product Images


HDS-1303NT
Press Brakes
CNC Pressbrake
used
(KG)
2006
$0.00

Description

System Specifications
Press Brake
Maximum Tonnage: 143 U.S. tons
Bend Length: 127 inches
Maximum Stroke Length: 7.87 inches
Open Height: 19.7 inches
Throat Depth: 16.3 inches
Distance Between Housings: 106.3 inches
Ram Repeatability: +/- 0.00004 inches
Approach Speed: 7.87 inches per second
Bending Speed: 0.78 inches per second (Max) programmable
Return Speed: 7.87 inches per second
Overall Machine Dimensions: 139" (L) x 116.9" (H) x 60" (W)
(174" (L) w/control to far left)
(88.6" (W) w/control in forward position)
Hydraulic Oil Capacity: 17.8 gallons
Machine Weight: 26,400 lb. Approx.

Backgauge
Repeatability
L Axis +/- 0.00008 inches
Movement Range
L Axis 27.55 inches
Y Axis 106.3 inches
R Axis 9.8 inches
Feed Speed
L Axis 1,180 inches per minute
Y Axis 2,362 inches per minute
X Axis 393 inches per minute

Minimum Command Unit
Ram 0.0001 inch
Backgauge 0.001 inch

CNC Controller, Model: Amada AMNC-PC
Axes of Control: Eight
D1 & D2 - Ram depth
(+/- 0.098" ram tilt)
L1 & L2 - Backgauge
(19.68" gauge taper maximum)
Z Vertical finger position
Y1 & Y2 - Horiz. finger movement, side to side
CC - Ram crowning
